Create, move, and manipulate drawing views By using shading, drawings can include more detail. Using shaded views in drawings gives more options for communicating critical design information since colors can provide visual cues to help describe designs. Take note of the shaded isometric view in the upper right corner. You can use the OLE (Object-Linking Embedding) capabilities for inserting images and other file types into your drawings. Not only has the drawing name, scale and date been filled in, but these values are linked back to the source model and will change if changed in the model - this insures complete accuracy of the information displayed.Īlso note the embedded jpeg logo image. Take note of the intelligence built into the format. Zoom in on the title block in the lower right corner of the drawing. These buttons toggle datum planes, axes, points and coordinate systems on and off so that your graphics window doesn't become too cluttered. To make drawing creation even easier, drawing templates can be used to automatically create a new drawing for each new part and assembly you create, thus saving you the need to do what you just did here.Ĭlick the Datum Planes, Datum Points, and Coordinate Systems icons in Pro/ENGINEER's main toolbar. The use of drawing templates can save an enormous amount of time by automatically laying out your standard view with dimensions, cross-sections, notes, etc. The template drawing will automatically layout the drawing. They automatically create the views, set the desired view display, create snap lines, and show model dimensions based on the template.Ĭlick OK from the New Drawing dialog box.

ĭrawing templates may be referenced when creating a new drawing.

Under the Template section, click Browse and select C_PART.DRW. Under Specify Template, select the radio button Use template. Note that the Use Default Template option is enabled.Ĭlick Browse from the New Drawing dialog box and select BOX.PRT as the Default Model. In the New dialog box, type BOX as the Name.

Ĭlick the New icon on the main toolbar and select Drawing as the Type in the New Object dialog box.

Right-click the DRAWING_TUTORIAL folder and select Set Working Directory. In the Navigator Folder Browser, browse to the following folder C:\HANDS-ON_WF3\DRAWING_TUTORIAL.

#PRO ENGINEER WILDFIRE 3.0 DOWNLOAD FULL WINDOWS#

If Pro/ENGINEER is already running ensure all windows are closed, and all items from the previous exercise are erased from memory. Start Pro/ENGINEER Wildfire 3.0 if necessary. Step 4: Make design changes in the model and in the drawing.Īs an alternative to having this open along-side Pro/Engineer, you can also view a printable version by clicking here. Step 3: Create, move and manipulate drawing details such as dimensions and notes. Step 2: Create, move, and manipulate drawing views

Both a part and assembly drawing will be created. In this tutorial, you will learn the basics of Drawing creation.

Icons and their names are shown inline with the text.

The "picks and clicks" are shown in Bold.

There are several conventions used in this tutorial:

Notes are provided as additional information.

Information is provided at the start of most tasks.

You will see various icons throughout the tutorial: Scroll through the entire contents before progressing to the next step. If the page contains more information than the visible screen, a scroll bar will appear along the vertical side. Click Home to return to the beginning of the tutorial. Click Next to proceed to the next slide and Previous to return to the previous slide. Use the Commands at the top of the page to navigate through the tutorial. It is recommended that you maximize the amount of working area on your screen by setting your monitor to the highest resolution setting, for example 1600x1200. Your web browser and Pro/ENGINEER can be resized and laid out as shown below to facilitate your experience.

Set your working directory to this location.įor example: C:\HANDS-ON_WF3\DRAWING_TUTORIAL.

#PRO ENGINEER WILDFIRE 3.0 DOWNLOAD FULL ZIP FILE#

Extract the zip file to a location on your hard drive.Ī plain drive letter (ex: C:\ ) is recommended.If not, please refer to the READ ME FIRST document.ĭownload the model files here. Files used or created during this tutorial cannot be used with any other version of Pro/ENGINEER other than the Tryout Edition. Your hosting Hands-on Workshop Application Engineer will have this set up for you. Please make sure that Pro/ENGINEER Wildfire 3.0 Tryout Edition is installed on your machine before continuing. This tutorial is intended to be used alongside Pro/ENGINEER Wildfire 3.0 Tryout Edition. Introduction to Creating Drawings in Pro/Engineer Introduction to Drawing Hands-On Workshop Pro/ENGINEER Wildfire 3.0
